High Speed Dynamic Weigh Price Labeller
HI-700II
Food IndustryMain Features
The HI-700ll's high speed and flexible label handling offers increased weighing and labelling efficiency in food production lines. The PC-based machine allows easy networking and integration with existing machines. Dynamic weighing and a high speed labeller allows up to 120ppm. Featuring a colour touchscreen for quick and easy programming and plu selection. Quick release conveyor system.
High productivity
The dynamic and high speed weighing and labelling application allows the HI-700ll to weigh and label up to 120 ppm.
High speed labeller
The high speed labeller provides fast application, large label roll diameter and 300dpi thermal print head. Different labelling applicators are available.
Windows operating system
The HI-700ll series uses an industrial PC, utilising embedded software on a Windows® operating system. This solution offers a flexible integration for bi-directional communication in XML format to back-office server data collection, programming and line monitoring.
Modular design
The modular design allows for the addition of extra labelling stations. Add more top and bottom labellers as required, allowing for the best solution for your requirements.
Specifications
Dimensions
Weighing
Capacity | Max 6 kg | Max 12 kg |
---|---|---|
Single Interval | e= 1g or greater | e= 2g or greater |
Display
Screen | 12" Colour LCD touchscreen |
---|---|
Touch panel | Pen/Finger resistive type |
Operation and general specification
Pack speed | up to 120 packs per minute |
---|
Pack size
Pack size capable | Length: 80 to 300mm, Width: 40 to 250mm, Height: 180mm maximum |
---|
for standard length scale of 475mm long
Labeler - high speed
Label size | width: 30 to 120mm, height: 28 to 150mm |
---|---|
Label roll | max 300mm diameter, 76mm core, inside/outside wound |
Label application system | 9 finger touch, Multijet air box |
Print speed | 50 to 260mm/sec |
Print head | 80mm at 300dpi, 108mm at 300dpi |
Variations
Top and bottom labelling
Long scale
Multi labeller
FAQ
-
Can the flow direction of the machine be left to right or right to left?The machine can be built to either flow direction.
-
What is the longest pack the HI-700ll can weigh?The HI-700ll can weigh a product up to 475mm long if using the optional 660mm scale
-
What is the widest pack the HI-700ll can weigh?The HI-700ll conveyor can handle a pack up to 250mm wide.
-
What is the pack speed of the HI-700ll?The HI-700ll has a maximum pack speed of 120 ppm. The speed depends on the size and weight of the pack.
